Canon EOS C300

  • 8.3MP Super 35mm CMOS sensor; Full HD
  • Interchangeable lens (EF mount)
  • Dual pixel CMOS AF for accurate and reliable focusing*
  • Compact, modular, lightweight
  • 50Mbps MPEG-2 MXF to CF card
  • High sensitivity, low noise
  • Canon Log Gamma
  • 24.00p for movie production
  • Wi-Fi remote control
  • Seamless workflow integration

Contact the Equipment Rental and Sales team

Jamie 2
Jamie Brewer
Head of Broadcast and Post Production Rental

Next up

SERVICES
Canon EOS C300

Features

8.3MP SUPER 35MM CMOS SENSOR; FULL HD


An 8.3MP Super 35mm CMOS sensor, designed and manufactured by Canon specifically for video capture, provides 3ch RGB processing for Full HD recording. Canon’s sensor technology delivers superb high-resolution images with high sensitivity, low noise, reduced rolling shutter artefacts and low power consumption, along with typical large sensor benefits such as beautifully shallow depth of field.

INTERCHANGEABLE LENS (EF MOUNT)


The EOS C300’s EF mount brings the optical heritage of Canon’s interchangeable EF lens system to a dedicated video production tool – expanding creative options through a huge range of affordable and unique lenses. 3 electronic built-in ND filters increase shooting versatility.

COMPACT, MODULAR, LIGHTWEIGHT


The EOS C300 is ultra-compact, with a basic recording set up that weighs just 1669g (without lens). Removable grip, handle and multi-angle control panel components ensure maximum manoeuvrability, whilst the robust, splash resistant body features magnesium alloy components for additional rigidity and toughness.

50MBPS MPEG-2 MXF TO CF CARD


Record broadcast-ready MPEG-2 MXF files at 50Mbps (4:2:2) to two CF memory cards – relay and simultaneous recording options are available. Industry-standard outputs include HD-SDI, along with Timecode, Genlock and Synch terminals for multi-camera shoots.

HIGH SENSITIVITY, LOW NOISE


The EOS C300 features enhanced sensitivity: low noise images can be captured at up to ISO 80000, allowing use in almost any shooting conditions.

CANON LOG GAMMA


Extensive image customisation includes built-in Canon Log Gamma, which delivers neutral image quality with wide dynamic range (800%) for maximum freedom in post-production. Adjust more than 90 image variables and store as Custom Picture profiles in-camera or on SD card.

24.00P FOR MOVIE PRODUCTION


PAL, NTSC, and 24.00p modes are included as standard, offering frame rates from 23.98p to 59.94i. Adjust slow and fast motion in 1fps steps for creative flexibility.

WI-FI REMOTE CONTROL


Wirelessly control camera settings such as ISO, focus, aperture and ND filters via a notebook, tablet or Smartphone, using a simple browser-based user interface. (Optional wireless adaptor required.)

SEAMLESS WORKFLOW INTEGRATION


Integrating seamlessly with existing workflows, EOS C300 movies are compatible with most widely-used professional NLE software packages.

DUAL PIXEL CMOS AF VIA SERVICE UPDATE


Your EOS C300 can be updated to incorporate Canon’s unique Dual Pixel CMOS AF, which offers incredible ease of use and creative control over focusing. It’s simple to track subjects continuously at the centre of the frame, keeping them in sharp focus. An AF-Lock function allows extra control. One-Shot focusing with enhanced accuracy and speed makes it just as easy to focus on off-centre subjects.


*Requires a chargeable service update at a Canon service centre.

Canon EOS C300

Specifications

Sensor

Super35mm type CMOS



System

RGB primary colour filter (Bayer array)



Total pixels per sensor

9.84 megapixels



Effective pixels per sensor

8.29 megapixels



Minimum illumination

NTSC Mode 0.3 Lux
[F1.2 lens , 24 dB, 29.97P mode, shutter speed 1/30]
PAL Mode 0.25 Lux
[F1.2 lens, 24 dB, 25.00P mode, shutter speed 1/25]



Sensitivity

NTSC: F9
[1920×1080/59.94i , ISO640 (0dB), 2000 Lux, 89.9% reflection]
PAL: F10
[1920×1080/50.00i , ISO640 (0dB) , 2000 Lux, 89.9% reflection]



S/N Ratio

NTSC: 54dB (Typical)
[1920×1080/29.97P, Canon Log base sensitivity ISO850 (Dynamic range 800%)]
PAL: 54dB (Typical)
[1920×1080/25.00P, Canon Log base sensitivity ISO850 (Dynamic range 800%)]



Dynamic Range

During normal shooting: 300%
With Canon Log gamma: 800%
(ISO 850 or above/gain 2.5 dB or more)



Horizontal Resolution

Up to 1000 TV lines or more (1920 x 1080i mode), depends on lens used



Lens Mount

Canon EF Mount



Focal length

Equivalent to 1.53x the focal length of EF lenses;
As indicated for EF-S lenses and Canon cine lenses



Peripheral illumination correction

YES (dependent on lens used)



ND filter

3 glass filters in camera body: 2 stops; 4 stops; 6 stops. Operate via body or wireless control



Focus control

Via lens, wireless control or wired remote (dependent on lens used) One shot AF with EF Lenses
(Not available with CINEMA lenses) Continuous AF available with EF-S 18 -55mm f/3.5 -5.6 IS STM or EF-S 18 – 135mm f/3.5 -5.6 IS STM Lens¹
DAF update optional (extra cost)



Iris control

Via body, grip, wireless control or wired remote. Push AI available with EF lens (Not available with CINEMA lenses) Continuous AI available with EF-S 18 – 135mm f/3.5 -5.6 IS STM Lens¹
1/2-stop, 1/3-stop or FINE control.
Possible to maintain constant F-number during zoom.



Image stabilization system

Depends on lens used



Type

DIGIC DV III
